ODESSA

Light Source:	High Power SMD LED >60000 Hours Life Span 3-Step MacAdams - LM80
LED Chip Brand:	Samsung / Osram
Color Rendering (CRI):	>70
Correlated Color Temperature (CCT):	3000K (Warm White - WW) 4000K (Natural White - NW) 6500K (Cool White - CW)
LED Module Board (PCB):	Metal Core PCB - White Finishing 1.5W/mK Heat Transfer Coefficient
Power Source:	Constant Current >60000 Hours Life Span ENEC Certified
Driver Brand:	Meanwell / Inventronics / Philips / Osram
Power Factor (PF):	>0,9
Driver Safety:	Overload Protection (OLP) Overvoltage Protection (OVP) Short Circuit Protection (SCP) Over Temperature Protection (OTP) Surge Protection (SP)
Housing:	Aluminium High Pressure Die Cast Injection
Optic:	4mm Tempered Glass PMMA Lens
Finishing:	Electrostatic Powder Coating Anthracite Grey Colour

Luminaire Type:	Road, Street & Landscape Lighting
Input Voltage:	220-230Vac / 50-60Hz
Luminaire Efficiency:	>120 Lm/W
IP Rating:	IP66
IK Rating:	IK08
Light Distibution Angle:	Asymmetric
Electrical Safety:	Class I
Ambient Temperature (Ta):	-10°C — +50°C
Installation:	Pole (Adjustable Console)
Warranty:	5 Years

Opsiyonlar:	CRI: >80 Dim: DALI / Astro Dim Output Power: 30-120Wmax. Efficiency (Lm/W): >125 / >130 / >140 CCT: 2700K / 5000K IP Seviye: IP65 / IP67 Ta: -20°C — +60°C Finishing: RALXXXX Warranty: 7 Year
Kullanım Alanlar:	Highways, Urban Roads, Streets Parks, Industrial Zones, Car Parking Lots Ports and Shipyards, Construction Sites

Model Name	Product Code	Power (W)	Efficiency (Lm/W)	Luminious Flux (Lm)	Colour Temperature (K)	Product Dimension (mm)			Datasheet	LDT File
Model Name	Product Code	Power (W)	Efficiency (Lm/W)	Luminious Flux (Lm)	Colour Temperature (K)	L	W / Ø	H	Datasheet	LDT File
Odessa-S	L&LSTP-MP04030-05217M128-GXYO66	40	128	5120	3000	519	172	67	indir	indir
Odessa-S	L&LSTP-MP04040-05217M135-GXYO66	40	135	5400	4000	519	172	67	indir	indir
Odessa-S	L&LSTP-MP04060-05217M134-GXYO66	40	134	5360	6500	519	172	67	indir	indir
Odessa-S	L&LSTP-MP05030-05217M126-GXYO66	50	126	6300	3000	519	172	67	indir	indir
Odessa-S	L&LSTP-MP05040-05217M132-GXYO66	50	132	6600	4000	519	172	67	indir	indir
Odessa-S	L&LSTP-MP05060-05217M130-GXYO66	50	130	6500	6500	519	172	67	indir	indir
Odessa-S	L&LSTP-MP06030-05217M122-GXYO66	60	122	7320	3000	519	172	67	indir	indir
Odessa-S	L&LSTP-MP06040-05217M129-GXYO66	60	129	7740	4000	519	172	67	indir	indir
Odessa-S	L&LSTP-MP06060-05217M128-GXYO66	60	128	7680	6500	519	172	67	indir	indir
Odessa-S	L&LSTP-MP08030-05217M119-GXYO66	80	119	9520	3000	519	172	67	indir	indir
Odessa-S	L&LSTP-MP08040-05217M126-GXYO66	80	126	10080	4000	519	172	67	indir	indir
Odessa-S	L&LSTP-MP08030-05217M124-GXYO66	80	124	9920	6500	519	172	67	indir	indir
Odessa-S	L&LSTP-MP10030-05217M116-GXYO66	100	116	11600	3000	519	172	67	indir	indir
Odessa-S	L&LSTP-MP10040-05217M123-GXYO66	100	123	12300	4000	519	172	67	indir	indir
Odessa-S	L&LSTP-MP10060-05217M120-GXYO66	100	119	11900	6500	519	172	67	indir	indir
Odessa-M	L&LSTP-MP12030-05726M126-GXYO66	120	126	15120	3000	573	264	67	indir	indir
Odessa-M	L&LSTP-MP12040-05726M132-GXYO66	120	132	15840	4000	573	264	67	indir	indir
Odessa-M	L&LSTP-MP12060-05726M131-GXYO66	120	131	15720	6500	573	264	67	indir	indir
Odessa-M	L&LSTP-MP14030-05726M121-GXYO66	140	121	16940	3000	573	264	67	indir	indir
Odessa-M	L&LSTP-MP14040-05726M127-GXYO66	140	127	17780	4000	573	264	67	indir	indir
Odessa-M	L&LSTP-MP14060-05726M125-GXYO66	140	125	17500	6500	573	264	67	indir	indir
Odessa-M	L&LSTP-MP15030-05726M117-GXYO66	150	117	17550	3000	573	264	67	indir	indir
Odessa-M	L&LSTP-MP15040-05726M122-GXYO66	150	122	18300	4000	573	264	67	indir	indir
Odessa-M	L&LSTP-MP15060-05726M121-GXYO66	150	121	18150	6500	573	264	67	indir	indir
