Technical Drawing

Product Code: L&LALP-LT001

Profile Dimensions (WxH): 50x70 mm

Profile Total Area: 428.50 mm²

Weight: 1.165 Kg/m

Maximum Length: 6.5 meters

Aluminum Alloy: 6060 T66

General Tolerance: TS EN 755-9

Paint: Electrostatic Powder Coating, Eloxal Coating

Mechanical Process: Drilling, Cutting, Welding

Technical Drawing

Product Code: L&LALP-LT002

Profile Dimensions (WxH): 50x40 mm

Profile Total Area: 274 mm²

Weight: 0.746 Kg/m

Maximum Length: 6.5 meters

Aluminum Alloy: 6060 T66

General Tolerance: TS EN 755-9

Paint: Electrostatic Powder Coating, Eloxal Coating

Mechanical Process: Drilling, Cutting, Welding

Technical Drawing

Product Code: L&LALP-LT003

Profile Dimensions (WxH): 70x75 mm

Profile Total Area: 504.50 mm²

Weight: 1.373 Kg/m

Maximum Length: 6.5 meters

Aluminum Alloy: 6060 T66

General Tolerance: TS EN 755-9

Paint: Electrostatic Powder Coating, Eloxal Coating

Mechanical Process: Drilling, Cutting, Welding

Technical Drawing

Product Code: L&LALP-LT004

Profile Dimensions (WxH): 43x35 mm

Profile Total Area: 171.12 mm²

Weight: 0.465 Kg/m

Maximum Length: 6.5 meters

Aluminum Alloy: 6060 T66

General Tolerance: TS EN 755-9

Paint: Electrostatic Powder Coating, Eloxal Coating

Mechanical Process: Drilling, Cutting, Welding

Technical Drawing

Product Code: L&LALP-LT005

Profile Dimensions (WxH): 35.80x35 mm

Profile Total Area: 172.90 mm²

Weight: 0.471 Kg/m

Maximum Length: 6.5 meters

Aluminum Alloy: 6060 T66

General Tolerance: TS EN 755-9

Paint: Electrostatic Powder Coating, Eloxal Coating

Mechanical Process: Drilling, Cutting, Welding

Technical Drawing

Product Code: L&LALP-LT006

Profile Dimensions (WxH): 66.40x84.40 mm

Profile Total Area: 851.10 mm²

Weight: 2.315 Kg/m

Maximum Length: 6.5 meters

Aluminum Alloy: 6060 T66

General Tolerance: TS EN 755-9

Paint: Electrostatic Powder Coating, Eloxal Coating

Mechanical Process: Drilling, Cutting, Welding
